32 Channel PM Fiber Array Polarization Maintaining Fiber Array 127um Pitch for Silicon Photonics Optical Coupling and Optical Module Packaging

Wholesale 32 Channel PM Fiber Array Polarization Maintaining Fiber Array 127um Pitch for Silicon Photonics Optical Coupling and Optical Module Packaging from china suppliers

Channel Count : 32

Core Pitch : 127 μm

Wavelength Range : 460-1950 nm

Insertion Loss : ≤0.5 dB

Contact Now

32 Channel PM Fiber Array Polarization Maintaining Fiber Array 127um Pitch for Silicon Photonics Optical Coupling and Optical Module Packaging

1. Product Overview

This product is a 32-channel PMFA polarization-maintaining fiber array with a 127 μm core pitch, supporting multiple operating wavelengths from 460–1950 nm.

2. Core Product Features

Parameter		Unit	32
Wavelength		nm	460,630,780,850,980,1060,1310,1550,1650,1950
Materials		-	Pyrex, Tempax, Quartz, Silicon
Lid Option			Lid / Lidless
CorePitch		-	127
Core Pitch Tolerance		μm	+/-0.5
Polish Angle		Degree	8°,41°,82°,90° or customized (12°, 21°,...) (±0.5°)
Angle Type		-	A Type or V Type
Insertion Loss		dB	≤0.5(Typical 0.3)
Polarization Extinction Ratio (PER)		dB	≥20 (Typical ≥23)
Polarization Axis Reference		-	Slow axis / Fast axis
Axis Orientation		Degree	0° /45°/ 90° / Customized
Axis Alignment Accuracy		Degree	≤ ±2° (Typ. ±1°)
Return Loss		dB	UPC≥45, APC≥55
FA Dimension	W	mm	5.7
	H	mm	2.5
	L	mm	12
	-	-	Standard or Customized
PM Fiber Type		-	Panda PM (standard) / Bow-tie (optional)
Fiber Coating		um	250 µm / 900 µm loose tube / ribbon (optional)
Fiber Type Length		cm	100+/-10 or customized
Connector		-	.FC/LC/SC/E2000/MT/MPO/MMC
Operation Temperature		°C	-5~65
Storage Temperature		°C	-40~85

32-channel high-density array structure
Excellent polarization-maintaining performance
Low loss and high return loss
Highly customizable design

32 Channel PM Fiber Array Polarization Maintaining Fiber Array 127um Pitch for Silicon Photonics Optical Coupling and Optical Module Packaging

3. Applications

Multi-channel polarization-maintaining fiber communication systems
Coherent optical communication modules
Silicon photonics chip coupling and photonic integration packaging
PLC, AWG, and multi-channel passive optical device packaging
Fiber optic sensing, interferometer, and polarization control systems
Laser, modulator, and detector array coupling
Laboratory precision optical path coupling and test measurement platform
